To bridge the gap between complex clinical needs and robust motor performance, we offer optimized configuration paths. Every solution is defined by duty-profile matching—prioritizing torque reserve and auditable validation to ensure patient safety and precise positioning in every cycle.
Motor Family: BLDC or Brushed DC (depending on product tier)
Performance: Controllable motion, compact size, and seamless integration with gearbox/screw modules
Options: Position feedback provision, harness/connector customization
Motor Family: PMSM (High-Efficiency)
Performance: Micro-motion capability and optimized smooth start/stop tuning
Options: Drive-ready matching plan, efficiency-optimized profiles
Motor Family: Single-phase AC induction or variable frequency (project-dependent)
Performance: Stable operation within legacy architectures and robust thermal control
Options: Market compliance planning, supply chain familiarity
Platform Shortlist + Option Spec + Validation Plan + Risk Checklist
Medical actuator motors are defined by intermittent duty and high-torque start cycles. The most common risk is not “motor quality”—it is mis-specified duty and insufficient load-endurance validation.
These platform families help us optimize within proven boundaries rather than forcing you into a fixed off-the-shelf model.
| Product Model | Rated power (HP) | Rated speed (r/min) | Rated torque (n· m) | frame size | Rated voltage (V) | Frequency (Hz) | Constant current (A) | Efficiency (η%) | Protection level |
|---|---|---|---|---|---|---|---|---|---|
|
BT16058LC1 |
0.5/0.75 |
2930/3470 |
2.0/2.5 |
56Y |
115 |
50/60 |
6.8/10.0 |
80.0/81.2 |
ODP |
|
BT16065LC1 |
0.66/1 |
2920/3470 |
2.7/3.4 |
56Y |
230 |
50/60 |
9.5/13.0 |
78.5/81.6 |
ODP |
|
BT16075EC1 |
1.1/1.5 |
2930/3490 |
4.0/4.5 |
56Y |
230 |
50/60 |
6.6/8.6 |
80.8/83.8 |
ODP |
|
VEV14075LCb |
1 |
3450 |
2.8 |
56J |
115/230 |
60 |
9.8/4.9 |
75.0 |
ODP |
|
VEV14095LCb |
1.5 |
3450 |
4.0 |
56J |
115/230 |
60 |
13.6/6.8 |
75.0 |
ODP |
Tailored for Clinical Motion Systems — We are your application-specific engineering partner.
Torque reserve, smooth start/stop, endurance planning
12V/24V programs + AC variants, market compliance planning
Coupling/gearbox interface, mounting envelope, wiring exit direction
Thermal protector, noise/vibration optimization, controller pairing (if BLDC/PMSM)
Ensuring clinical reliability through rigorous risk verification before mass production.
Load endurance cycling based on representative stroke and load profile simulation.
Verification of temperature rise under repeated duty cycles to ensure motor longevity.
Strict noise and vibration checkpoints tailored for ward and ICU sensitivity.
Routine electrical safety tests and backup-mode behavior verification.
Get Template
Frequent duty cycles + High patient weight + Strict acoustic sensitivity in ICU environments.
Linear Actuator Platform + Specialized low-noise gearbox + Reinforced stroke housing.
Max Load 8000N verified; Noise < 45dB verified; 10,000+ cycle life verified.
We map the dynamic push/pull force against the clinical duty cycle (e.g., 10% or 2 min on/18 min off). Selection depends on peak starting torque and sustained weight (6000N/8000N) to ensure efficient, long-term performance without mechanical fatigue.
Our motors integrate thermal cut-off switches and current-limiting sensors. We design with a thermal margin for repeated ICU posture adjustments, ensuring the motor housing remains within safe clinical temperature limits during heavy-load stalls.
Yes. Honest Motors provides soft-start/stop algorithms to eliminate patient discomfort from sudden jerks. We tune motor ramping to achieve micro-motion precision while keeping acoustic levels under 45dB for quiet ward environments.
We offer dedicated 12V DC interfaces for battery integration. Our validation includes backup behavior verification, ensuring the actuator can return to a “Safety Low” position during power outages under full-rated patient load.
We deliver a complete Compliance Doc Pack: UL/CE raw material certs, dielectric test reports, and UDI traceability data. This supports your ISO 13485 and EN 60601-1 risk management workflows for medical device certification.
